Insertion Type Electromagnetic Flow Meter

Located in Pune, a hub of industrial innovation, SaiTechFlow has become a leading manufacturer and supplier of Flow Measurement & Instrumentation Solutions across India.

Our range of Electromagnetic Flow Meters — including Full Bore, Insertion Type, Battery Operated, and Sanitary Flow Meters — are designed with international quality standards and indigenous manufacturing excellence.

We cater to industries such as:

• Water & Wastewater Treatment
• Irrigation and Canal Systems
• Chemical Processing Plants
• Power Generation
• Oil & Gas Pipelines
• Steel, Cement & Mining Sectors
• Municipal Water Distribution Networks

With a strong technical base and field experience, SaiTechFlow ensures every product offers accuracy, durability, and reliability at competitive pricing.

Working Principle

The Insertion Type Electromagnetic Flow Meter operates on Faraday’s Law of Electromagnetic Induction.
When a conductive liquid flows through a magnetic field generated by the sensor, it induces a voltage proportional to the flow velocity.

The meter’s electrodes, in contact with the fluid, pick up this induced voltage, which the transmitter electronics convert into a corresponding flow rate.

Mathematically,

E = K × B × D × V
Where:

• E = Induced Voltage
• B = Magnetic Field Strength
• D = Distance between Electrodes
• V = Velocity of Fluid
• K = Constant

This simple yet precise principle ensures high accuracy, independent of pressure, temperature, or viscosity, making it one of the most dependable flow measurement techniques in the industry.

 Technical Specifications

 Key Features of SaiTechFlow Insertion Type Mag Flow Meter

• ✅ Ideal for Large Diameter Pipes – cost-effective for DN150 and above
• ✅ No Pressure Drop – unobstructed flow path ensures energy-efficient operation
• ✅ Easy Installation – suitable for existing pipelines using saddle or hot-tap assembly
• ✅ Smart Transmitter Options – digital display with totalizer, Modbus, and 4–20mA output
• ✅ Low Maintenance – no moving parts, no mechanical wear
• ✅ Custom Probe Lengths – designed as per pipeline diameter and process conditions
• ✅ High Durability – stainless steel probe and industrial-grade electronics
• ✅ Compatible with Various Fluids – water, wastewater, chemicals, slurries, and more
• ✅ Remote or Integral Mounting – flexibility for site installation and visibility

 Applications

Our Insertion Type Electromagnetic Flow Meters are trusted across diverse industries for applications such as:

• Municipal Water Distribution – flow monitoring in main supply lines
• Wastewater & Effluent Plants – accurate flow control in large pipelines
• Irrigation & Canal Systems – reliable flow data for agricultural management
• Industrial Utilities – chilled water, cooling water, and process water measurement
• Chemical Industries – non-corrosive and conductive liquid flow monitoring
• HVAC & Power Plants – cooling circuit and feedwater systems
• Slurry & Mining Applications – suitable for conductive slurry measurement with rugged design

 Advantages of Using SaiTechFlow Insertion Type Flow Meters

1. Cost-Effective Solution:
   Perfect for large pipes where full-bore flow meters would be expensive.
2. Minimal Pipeline Modification:
   Installation requires only a small insertion hole — ideal for retrofitting in existing systems.
3. Quick Maintenance:
   The probe can be removed for cleaning or calibration without dismantling the main line.
4. Versatile Communication:
   Compatible with PLCs, SCADA, and automation systems via Modbus or 4–20 mA output.
5. Durable Design:
   Industrial-grade materials and IP-rated housings ensure long-term operation.
6. Energy Saving:
   No obstruction to flow means no pressure drop and minimal energy loss.
7. Made in India, Engineered for the World:
   Designed and manufactured in Pune with adherence to global standards.

 Why Choose SaiTechFlow?

• Expertise in Flow Measurement – Years of experience in developing electromagnetic flow solutions
• Quality Assurance – Every unit tested and calibrated on certified flow test benches
• Customization – Meter designed as per site conditions and pipeline diameter
• After-Sales Support – On-site commissioning, AMC, and technical training available
• National Reach – Supplying across India with prompt delivery and service

When you partner with SaiTechFlow, you get more than a product — you gain a reliable measurement partner dedicated to your process accuracy.

 Quality & Certification

Every Insertion Type Electromagnetic Flow Meter from SaiTechFlow undergoes rigorous quality checks and calibration before dispatch.
Our manufacturing follows ISO 9001:2015 standards, and all meters are provided with:

• Calibration Certificates
• Test Reports
• Warranty Documents

We ensure consistency in performance and reliability across every application.

 Installation and Mounting Options

SaiTechFlow offers two types of insertion systems:

1. Fixed Installation:
   Suitable where the process can be shut down during installation.
2. Hot-Tap Installation:
   Allows insertion and removal without interrupting the process — ideal for continuous flow systems.

Each setup is supported by mounting accessories such as saddles, ball valves, extension rods, and remote transmitters for complete flexibility.

 Industries We Serve

• Water & Wastewater
• Power Plants
• Chemical & Petrochemical
• Food & Beverage
• Pharmaceuticals
• Irrigation & Agriculture
• Pulp & Paper
• Steel, Cement & Mining

Our meters have been installed across India and overseas, earning SaiTechFlow a strong reputation as a dependable Electromagnetic Flow Meter Manufacturer in Pune, India.

 Conclusion

For industries seeking a dependable, cost-effective, and easy-to-install solution for large-diameter flow measurement, the Insertion Type Electromagnetic Flow Meter from SaiTechFlow is the ideal choice.

With advanced technology, superior accuracy, and field-proven reliability, SaiTechFlow continues to set benchmarks in flow instrumentation and process automation.

✅ Measure with confidence. Monitor with precision. Flow with SaiTechFlow.
